The engine belt looks simple, but it is a key component of the equipment. Each belt is responsible for driving a specific equipment component. Whether you open a repair shop or maintain your equipment yourself, understanding different types of engine belts can help you make more reliable replacement decisions and avoid failures that cause high losses.
What Are Engine Belts?
The engine belt is a flexible loop belt made of durable rubber. It is also reinforced with fibers such as Kevlar or polyester to increase strength and prevent stretching. The main function of the belt is to transmit the power of the engine crankshaft to various key components to make the machine work properly. The belts of heavy equipment work for a long time in dusty, muddy, high-temperature, and heavy-load environments, and are under great pressure. Regularly checking your belts and understanding the different types can help you avoid sudden equipment downtime and high repair costs.
Serpentine/Ribbed Belt
The serpentine belt (also called a ribbed belt or poly-groove belt) is the most common type on modern heavy equipment. True to its name, this single long belt snakes its way around multiple pulleys. It drives all the engine’s accessories in one go, using just one loop.
Its outer side is flat. The inner side has a row of small V-shaped ribs. These ribs fit perfectly into the matching grooves on the pulleys. This creates a large contact area for a strong grip and efficient power transfer. This efficient design lets engineers make engine bays smaller and more powerful. But it has one big downside—it’s a single point of failure. If the serpentine belt breaks, every part it powers (water pump, alternator, etc.) stops working right away.
V-Belt
Before serpentine belts became common, V-belts were the primary mode of drive for engine accessories. They are still commonly found in older or simple heavy equipment, such as old bulldozers, small generator sets, or some basic agricultural machinery.
V-belts have a “V”-shaped cross-section. This shape fit tightly into the groove of the pulley. The greater the load, the tighter it bites, the higher the friction, and the less likely it is to slip.
Equipment using V-belts typically does not have one belt responsible for all accessories, but rather several separate belts working separately. For example, one belt drives an alternator and the other drives a water pump or fan. The advantage of this is that there is a certain degree of redundancy—if one of them breaks, it will only affect that part and the rest of the engine will continue to run for a while.
What’s the Difference Between V-Belts and Ribbed Belts?
Both belts transfer power, but their designs and uses explain why modern equipment has switched to serpentine systems.
- Design & Contact: A V-belt works by wedging itself into the pulley groove. It only makes contact with the two sides of the groove. A ribbed (serpentine) belt touches the bottom of its many tiny ribs. This creates a bigger, more evenly spread contact area for better friction.
- Flexibility & Routing: Ribbed belts are thinner and more flexible than V-belts. They can be routed in tight, winding paths around multiple pulleys. They can even bend backward over smooth idler pulleys. V-belts are stiffer. They’re almost always used in simple setups with just one or two pulleys.
- Tension & Efficiency: Ribbed belts work well even with lower tension. This cuts down on wear for pulley bearings and boosts overall engine efficiency. The V-belt’s wedging action gives it good grip, but it creates more friction. It also needs higher tension to work properly.
- Application: V-belts are great for high-torque, single-component drives. They’re tough and perfect for simple systems. Ribbed belts are the standard for modern, compact, high-output engines. They handle complex setups that drive multiple accessories at once.
Here’s a simple way to think about it: V-belts are like a team of specialists. Each one does just one job. A serpentine belt is a single, multi-talented all-rounder that handles everything. Both have their uses, but the all-rounder is far more common these days.
Hydraulic Pump Belt
Although the main serpentine belt of some equipment can drive the power steering pump, many heavy machines, such as skid steer loaders, mini excavators, and small tractors, use a separate belt to drive their hydraulic pumps.
This hydraulic pump belt is very critical because the hydraulic pump is responsible for providing the main working power, such as lifting the boom, rolling up the bucket, or driving accessories such as augers and breakers. Once this belt breaks, the engine can continue to run, but the working movement of the machine will stop. The boom will not be raised, the bucket will not be rolled, and the accessories will not be able to be brought.
Because the hydraulic system requires a lot of torque, this belt is usually stronger than ordinary belts. It may be a strong V-belt or a short, wide ribbed belt designed to withstand high loads.
PTO Belt
The PTO belt is another specialized belt. You’ll mostly find it on agricultural and forestry machinery—tractors, combines, mowers, and the like. PTO stands for Power Take-Off. It’s a system that moves engine power to external, usually detachable, equipment. The PTO belt gets power from the tractor’s dedicated PTO shaft. It uses that power to run tools like balers, sprayers, or cutters. These belts are built to be super tough. They work out in the open and have to handle the shock loads from starting up and running heavy attachments. Important note: They’re a totally separate system from the engine’s internal accessory belts.
Fan Belt & Water Pump Belt & Alternator Belt (Accessory Drive Belt)
These terms are often used interchangeably. They usually refer to individual V-belts in older engine setups. Before the single serpentine belt came along, it was standard to have separate belts for different jobs:
- A fan belt: To spin the engine’s large cooling fan.
- A water pump belt: To circulate coolant.
- An alternator belt: To generate electricity.
In many cases, one single V-belt could drive two components, like the water pump and fan. When someone talks about an “accessory drive belt” on an older machine, they’re almost always referring to one of these specific V-belts. On modern heavy equipment? All those separate belt jobs have been rolled into one single serpentine belt.
When Do the Engine Belts Need Replacement?
Knowing the signs of a failing belt can save you from a breakdown on the job.
- Squealing or Chirping Noises: A loud squeal, especially when starting the engine or under heavy load, usually means a slipping belt. This is caused by low tension or wear. A rhythmic chirp typically points to pulley misalignment.
- Visible Wear and Damage: Cracked ribs, shiny glazed spots, frayed edges, or missing chunks. These signs mean the rubber is aging, slipping, or rubbing against parts it shouldn’t. Any physical damage weakens the belt.
- Accessory Performance Issues: If your machine overheats, the battery won’t charge (battery light on the dash), or the cab A/C is weak, a slipping or failing belt is likely the cause.
- Loss of Hydraulic Power: On machines with a dedicated hydraulic pump belt, sudden loss of attachment function links directly to that belt failing.
Most manufacturers suggest replacing belts based on operating hours. Always check your machine’s service manual for the exact replacement interval.
