Struggling to find a quality replacement oil filter for your lawnmower, tractor, or generator? You don’t have to put your yard work on hold. Using a Kohler oil filter cross-reference is the ultimate shortcut to swap your hard-to-find factory filter with highly reliable, budget-friendly alternatives from household brands like WIX, Fram, and Purolator. But while these aftermarket options offer identical filtration specs, choosing the wrong model can lead to devastating oil leaks or engine damage. Keep reading to unlock our complete Kohler cross-reference chart, discover the hidden benefits of going aftermarket, and learn the step-by-step process to choose and install your new filter safely.
What Is A Kohler Oil Filter Cross Reference Chart?
A Kohler oil filter cross-reference chart is a comprehensive lookup tool that matches Kohler original equipment manufacturer (OEM) oil filter part numbers with compatible aftermarket equivalents from other trusted brands, such as Fram, Wix, Baldwin, and Purolator. Since Kohler engines are widely used in lawnmowers, generators, and outdoor power equipment, finding a direct OEM replacement locally can sometimes be difficult. A cross-reference chart allows equipment owners, mechanics, and DIYers to quickly identify alternative filters that share the exact same thread size, gasket diameter, bypass valve rating, and filtration specifications, ensuring a safe and perfect fit for their engine.
Benefits of Using Cross-Reference Filters
Using the cross-reference chart to find oil filter equivalents delivers many benefits:
- Availability: Oil filter equivalents are sometimes easier to find and more widely stocked. If your local dealer or specialty store is out of stock of official Kohler OEM filters, you can easily find a compatible alternative at any standard parts store or major retailer.
- Cost Savings: Aftermarket equivalents often cost less than OEM filters. Choosing a cross-referenced brand allows you to maintain your engine’s health and perform routine maintenance without paying the premium price tag.
- Performance Options: High-quality aftermarket oil filters may offer synthetic media or higher capacity. Many premium aftermarket brands design filters with advanced synthetic blend media, sturdier silicone anti-drainback valves, and larger canister volumes that can capture smaller particles and hold more debris than standard factory filters.
- Redundancy: Multiple options ensure replacement filters are available when needed. Having a list of several compatible part numbers from different brands guarantees that you will always be able to source a replacement filter, preventing maintenance delays even during supply chain shortages or peak seasons.
Kohler Oil Filter Cross Reference Chart
The quick cross-reference chart lists the OEM Kohler part numbers and the replacement part numbers of their equivalent oil filters from four reputable brands: WIX, Fram, Purolator and Baldwin.
| Kohler OEM Number | Thread / Size | WIX | Fram | Purolator | Baldwin |
|---|---|---|---|---|---|
| 12‑050‑01 / 12‑050‑01‑S | ¾″‑16 | 51056 | PH3614 | L10241 | B7165 |
| 52‑050‑02‑S | ¾″‑16 | 51348 | PH7575 | L10241 | B7165 |
| 5205002S | ¾″‑16 | 51056 | PH3614 | L10241 | B7165 |
| 12‑070‑01‑S | ¾″‑16 | 51097 | PH3606 | L10441 | – |
| 12‑050‑08‑S | ¾″‑16 | 51348 | PH3614 | L10241 | – |
| 12‑050‑09‑S | ¾″‑16 | 51056 | PH3614 | L10241 | – |
| 52‑050‑04‑S | ¾″‑16 | 51348 | PH7575 | L10241 | – |
| 12‑050‑03‑S | ¾″‑16 | 51056 | PH3614 | L10241 | – |
| 12‑050‑05‑S | ¾″‑16 | 51097 | PH3606 | L10441 | – |
| 277233‑S | 1″‑14 | 51502 | PH2876 | – | B240 |
| 12‑050‑11‑S | ¾″‑16 | 51097 | PH3606 | L10441 | – |
| 52‑050‑07‑S | ¾″‑16 | 51348 | PH7575 | L10241 | – |
How to Choose the Right Replacement Oil Filters with A Cross-Reference Chart?
Selecting the correct oil filter replacement for Kohler is super easy with a cross-reference chart. Here are the steps for you to follow:
- Identify your oil filter part number by checking the filter canister on your engine or consulting your engine manual.
- Consult the Kohler cross-reference chart to find compatible filters from reliable aftermarket brands.
- Confirm critical elements of your oil filter, including the thread size, seal, and filter length, for a perfect fit.
- Install the replacement oil filter properly by carefully oiling the gasket, screwing the filter on, and checking for leaks after starting the engine.
- Change your oil filter according to the recommended intervals, typically 50-100 hours or annually, whichever comes first.
In this way, you can source the correct oil filter replacement for your Kohler engine without difficulty.
Maintenance Tips for Your Kohler Oil Filter
When it comes to replacing your Kohler oil filter, it’s essential to lubricate the rubber gasket with a little clean engine oil. Always make sure you choose the oil with the right oil grade as specified in your owner’s manual. During installation, it’s better to tighten the oil filter by hand until the gasket contacts the mounting surface and then turn it an additional ¾ turn. One golden rule is to check for leaks after starting the engine. Below is the Kohler engine oil viscosity chart for your reference:
Kohler Engine Oil Chart
Choosing the right engine oil for your Kohler engine is vital for proper lubrication, fuel efficiency and extended engine service life. The table below shows the recommended oil viscosity and oil type for your Kohler engine based on temperatures.
| Temperature Range (°F / °C) | Recommended Oil Viscosity | Oil Type |
|---|---|---|
| Below 0°F (-18°C) | 5W-20, 5W-30, 10W-30 | Synthetic or Conventional |
| 0°F to 32°F (-18°C to 0°C) | 10W-30, 10W-40 | Synthetic or Conventional |
| 32°F to 80°F (0°C to 27°C) | SAE 30 | Conventional |
| Above 50°F (10°C) | SAE 30, 15W-40, 20W-50 | Conventional |
| All Temperature Ranges | 5W-30, 10W-30 | Full Synthetic |
Final Thoughts
Kohler engines perform best when equipped with the right oil filter. While OEM Kohler filters ensure reliable performance, aftermarket alternatives provide flexibility, availability and economy. By using the Kohler cross-reference chart, checking oil filter specifications carefully and performing regular engine oil and filter maintenance, you can protect your Kohler engine and extend its service life. If you unfortunately got a failed oil filter, you can explore a vast selection of quality oil filters from FridayParts at an affordable price. Explore now and enjoy smooth operation.
