When buying a new or used Kubota farm tractor or sourcing aftermarket parts, it is essential to consider the specs of the model before making a purchase. Today, we’ll bring up another guide on Kubota M6060 specs and parts lookup for you.
What Is A Kubota M6060 Tractor?
The Kubota M6060 is a powerhouse of versatility, designed to tackle a broad range of agricultural and maintenance tasks. Featuring its 63.5 engine HP and 56 PTO HP, it stands ready to deliver superior performance. Its suite of features, like a hydraulic shuttle, ultra grand cab, underlines the capability and adaptability. And its optional enhancements, like the air ride seat, display Kubota’s commitment to operator comfort and efficiency. All these features make the M6060 a popular choice among many farmers.
Key Features of Kubota M6060 Tractor
Common Rail System (CRS) with EGR and DPF Muffler
As a proud member of M60 Series, the Kubota M6060 features a blend of efficient Common Rail System and the environmental stewardship of Exhaust Gas Recirculation and a Diesel Particulate Filter Muffler. This setup embodies the formidable performance and the commitment to emission reduction and ecological compatibility.
Engine Horsepower and PTO
Kubota M6060 stands out in its robust engine with a solid 63.5 horsepower and 56 56 PTO HP. This allows it to have the power for demanding tasks while maintaining efficient operation across different applications.
Ultra Grand Cab
The ultral grand cab is a symbol of comfort, equipped with heating, air conditioning and optional heated rear glass. And it is ergonomically designed with the operator in mind, giving priority to comfort and functionality. The adjustable seating and accessible controls reduce fatigue, making the field work more productive and manageable.
Telescopic Lower Link Ends and 3-Point Hitch
The Kubota M6060 boasts a lifting power of 3307lbs with its telescopic lower link ends and a high-capacity 3-point hitch. This facilitates easier implement attachment and adjustment and showcases the versatility and strength of the tractor.
Bevel-Gear Front Axle
The tractor’s bevel-gear front axle enhances its all-around maneuverability, providing a tighter turning radius and improved stability, which helps navigate tight spaces and challenging terrains.
Hydraulic Shuttle
Featuring a hydraulic shuttle, the Kubota M6060 tractor allows for smooth and efficient transitions between forward and reverse, enhancing operational efficiency without the need for clutch engagement.
Optional Air Ride Seat
The optional air ride seat provides unparalleled comfort by mitigating shock and reducing the operator’s fatigue. This embodies Kubota’s devotion to enhancing the user experience during operations.
Detailed Kubota M6060 Specs
| Engine | |||||
|---|---|---|---|---|---|
| Make & Model | Kubota V3307-CF-TE4 | Fuel Type | diesel | Aspiration | turbocharged |
| Cooling | liquid cooled | Displacement | 203 ci 3.3 L | No of Cylinders | 4 |
| Emission | Tier IV | Emission Control | EGR | Power(net) | 63.5hp 47.4kW |
| Fuel system | common rail direct injection | Rated RPM | 2,400 | Starter | electric |
| Starting Volts | 12 |
| Transmission | |||
|---|---|---|---|
| Type | power shuttle | Gears | F8 x R8 |
| Clutch | wet disc | Wheel Drive | 4WD |
| Other | four synchronized gears (1-4) in two ranges (low/high) |
| Dimensions & Tires | |||
|---|---|---|---|
| 2WD Wheelbase | 84.4 inches 214 cm | 4WD Wheelbase | 83.1 inches 211 cm |
| 2WD Length | 142.7 inches 362 cm | 4WD Length | 138 inches 350 cm |
| Width | 73 inches (min) 185 cm | Height (ROPS) | 96.9 inches 246 cm |
| Height (cab) | 100.6 inches 255 cm | Clearance (front axle) | 18.1 inches 45 cm |
| Clearance (front axle) | 18.1 inches 45 cm | Front tread | 55.9 to 71.7 inches 141 to 182 cm (2WD) |
| Front tread | 55.9/59.8 inches 141/151 cm (4WD) | Rear tread | 55.9 to 67.7 inches 141 to 171 cm |
| Tires (2WD) | Front: 7.5-16. Rear: 16.9-28 | Tires (4WD) | Front: 9.5-24. Rear: 16.9-28 |
| Electrical | |||
|---|---|---|---|
| Ground | negative | Charging system | alternator |
| ROPS Charging amps | 45 | Cab Charging amps | 60 |
| Optional Charging amps | 100 | Battery volts | 12 |
| Tractor Hitch | |||
|---|---|---|---|
| Rear Type | II/I | Control | position control and top-link draft sensing |
| Rear lift (at 24″/610mm) | 3307 lbs 1500 kg | Rear Arms | telescopic lower link ends |
*Sourced from TractorData
Maintenance Intervals & Replacement Parts for Kubota M6060 Tractor
|
Parts & Links |
Part Numbers | Maintenance Intervals |
|---|---|---|
| Engine Oil Filter | HH1C0-32430 | every 200 hrs |
| Fuel Filter | 1J800-43170 | every 400 hrs |
| Air Filter Kit | 59800-26110 | clean at 100 hrs
(Primary Air Filter) |
| Hydraulic Filter | HHTA0-37710 | every 400 hrs |
| Filter kit | 59800-26110/3A111-19130/HH1C0-32430/HHTA0-37710/1J800-43170 | recommend changing altogether |
| Hydraulic/Transmission Fluid | Super UDT2 | change every 400 hrs |
Kubota M6066 Common Problems
Problem #1: DPF Regen Warnings and Forced Shutoff
DPF and EGR regen failures are the most consistently reported M6060-specific complaint.
Symptoms
- DPF warning light on dash
- Tractor shuts down after 10-20 minutes of idle or light load operation
- Frequent parked regen requests
- Fault codes P24xx appearing on scan tool after ignoring the warnings
- Power returns fully after completing regen cycle
Causes
- Clogged DPF from short work cycles and extended idling
- EGR valve soot buildup restricts exhaust flow and prevents regen temperatures
- Faulty DPF pressure or temperature sensor triggers false warnings
- Early production DPF sensor sensitivity
Fixes for M6060 DPF Regen
- Check DPF% on dash — below 85% is acceptable
- Keep working at rated RPM and do not park or shut down when the regen lamp is on
- Run passive regen at high RPM under real load for 30+ minutes
- If parked regen requested, park in an open area away from combustibles and follow the operator manual
- Never interrupt a parked regen cycle
- If regen fails repeatedly, scan for fault codes before chasing mechanical causes
- Turn to Dealer for ECU inspection when regen failures persist after correct operation
Problem #2: Fuel Shutoff and No-Start
Symptoms
- Tractor runs 2-5 minutes and then dies suddenly
- The engine shuts off without warning during operation
- Cranks but won’t fire
- Fuel hose weeping or visible dampness around the filter housing
Causes
- Water or contaminated fuel in tank
- The clogged primary fuel filter restricts flow under load
- Air leak at the filter housing or primer pump, allowing air into the system
- Weak lift pump, which reduces delivery under sustained demand
Fixes
- Drain a small fuel sample into a clear jar and you can see a distinct layer at the bottom of the water
- Replace fuel filter 1J800-43170 and check filter housing O-rings and fittings for air leaks
- Bleed the air out of the fuel system after the replacement
See How to Bleed Diesel Fuel System for reference.
Problem #3: Hydraulic Weakness and No Lift
Symptoms
- Loader lifts slow or jerky under full load
- 3-point hitch drifts down with implement attached
- Hydraulic pump whining
Causes
- Low or contaminated HST/hydraulic fluid
- A clogged hydraulic suction filter restricts the pump inlet
- Air in the hydraulic circuit after maintenance or low fluid levels
- Internal pump wear in high-hour machines
Fixes
- Check the combined hydraulic/transmission sump
- Replace the clogged hydraulic filter
- Cycle loader and 3-point lock-to-lock 10+ times with engine running to purge air after any fluid service
See How to Check Hydraulic Fluid for Your Kubota Tractor for reference.
Problem #4: Engine Overheating
Symptoms
- Temperature gauge spikes under sustained load
- Radiator is visually clean but overheating persists
- Power reduction as engine thermal protection activates
- Coolant overflow tank losing fluid over time
Causes
- EGR cooler clog
- Bad thermostat that stuck open or closed
- Water pump leak or reduced flow
- Low coolant
Fixes
- Flush and replace coolant
- Test and replace thermostat if stuck
- Pressure test the cooling system for leaks
- Inspect your EGR cooler if overheating persists with clean system
See How to Pressure Test Your Cooling System for reference.
Conclusion
Whether you’re buying a new or used Kubota M6060 or sourcing replacement parts for repairs and maintenance, it is essential to know the specs clearly and the part numbers. Also, you must refer to your owner’s manual when performing any DIY repairs or maintenance. At FridayParts, you can learn from our blogs many helpful expertises on tractor troubleshooting, maintenance & repairs and you can browse our websites for a vast range of high-quality Kubota replacement parts for your tractor.
